Van Semi-trailer-Cargo Trailer-OSV9400XXYYK

Product Description

Van Semi-trailer-Cargo Trailer-OSV9400XXYYK

OROSOL^® can produce Van Semi-trailer-Cargo Trailer-OSV9400XXYYK.

Item Name: OROSOL^® Van Semi-trailer-Cargo Trailer-OSV9400XXYYK.

Brand: OROSOL^®

OROSOL^® can produce Van Semi-trailer-Cargo Trailer-OSV9400XXYYK.

*************************************

OROSOL^® Van Semi-trailer-Cargo Trailer-OSV9400XXYYK Vechicle Parameter

Brand Name			OROSOL®			Model Number			OSV9400XXYYK
Dimensions (mm)			14600×2550×3980,3780,3380			Total Mass (kg)			40000
Curb Weight (kg)			8500			Rated contained mass (kg)			31500
Semi-trailer saddle			16000			Cargo body dimension (mm)			14250×2400×2400,2200,1800
approach/departure angle °			-/11			Overhang F/R (mm)			-/2800
Axle load			-/24000			Wheel base (mm)			7580+1310+1310
Number of axles			3			Number of spring pieces			-/8/8/8,-/10/10/10,-/12/12/12
No.of tires			12			Tyre size			12R22.5 12PR,11.00R20 12PR

Notes:

1. Install ABS with the chassis.

2. The top of this carriage is closed and cannot be opened. Side doors are selected on the side, and the compartment panels are made of corrugated or flat plates. For use only on high-grade highways. The side protection material is Q235, which is connected by bolts. The rear protective material is Q235, of welded type, with a cross-sectional size of 150×70mm and a height from the ground of 540mm.

*************************************

Semitrailer Production Base

OROSOL^® Semitrailer Production Base is a globally leading high-end manufacturing base for semi-trailers and special vehicles, a pioneer in the high-quality development of China's road transport equipment, and an explorer and innovator in the field of new energy special vehicles in China.

OROSOL^® Semitrailer Production Base mainly engages in the design, production, and sales of global semitrailers; Provide professional installation design, manufacturing, and after-sales service for new energy heavy-duty truck chassis, assist leading new energy heavy-duty truck production enterprises with close cooperative relationships, and complete the value chain closed loop of heavy-duty new energy special vehicles; And the design, manufacturing, and sales services of pure electric locomotive mounted trains.
